PowerCore 2s.6s Scatola Alimentazione 2x S19 6x Schuko - SHOWGEAR E617022
The Showgear PowerCore 2s.6s is a breakout power box with two Multipin S19 connectors (male/female) and high-quality 6 Schuko outlets from PCE. Its loop-through design connects all channels from input to output, while simultaneously powering the Schuko sockets for efficient distribution. Each outlet includes a voltage indication LED for quick and convenient status checks. It is designed for seamless integration with the Showgear PowerCore series and is compatible with all PowerCore units equipped with a Multipin S19 output connector, as well as other power distributor brands with Socapex 19-pin connectors.
For flexible installation, the PowerCore 2s.6s offers multiple mounting holes for permanent setups and a quick-lock mounting point for fast, tool-free attachment using the optional PowerCore Quick Lock Bracket.
- 2 Multipin S19 connectors (1 in, 1 out) with loop-through functionality
- 6 Schuko outlets from PCE
- Voltage indication LED on each output
- Compatible with Multipin S19 and Socapex 19-pin connectors
- Quick-lock mounting option for easy installation
| Power Supply | 230 V AC 50/60 Hz |
|---|---|
| Rated Current (A) | 16 A |
| Power Connector In | Multipin S19 |
| Power Connector Out | Schuko Socket / Multipin S19 |
| Length (mm) | 310 mm |
| Height (mm) | 102 mm |
| Width (mm) | 175 mm |
| Weight | 2.7 kg |
| IP Rating | IP20 (indoor use only) |
| Material | Metal |
| Colour | Black |
| LED Indicators | Power |
| Maximum Ambient Temperature | 40 °C |
| Minimum Ambient Temperature | -5 °C |
| Mounting Options | Quick-Lock / Wall |
| Fixed Mounting Option | 11 mm |
| Safety Attachment | Yes |
