The Showtec Cameleon Pixel Bar 15 Q6 Tour is a powerful 15x 10 watt LED Bar with individually controllable LED pixels, silent, fanless operations and IP65 rating, suitable for indoor and temporary outdoor applications. It has a 33° fixed horizontal and 22° vertical beam angle and features 0-100 % dimmer and 0-15 Hz strobe effects, perfectly suitable for colour mixing on stage. The Cameleon Pixel Bar 15 Q6 Tour can be controlled manually, via DMX, IR remote, and Master/Slave in either Manual or Auto run mode with many available built-in programs. It is equipped with Seetronic Power Pro True IP65-rated power connectors, which are compatible with the leading brands.
- 15 individually controllable 10 W RGBWA-UV LEDs
- Perfect for colour mixing on stage
- IP65 (dust and water resistant, suitable for temporary outdoor use)
- 33°x 22° fixed beam angle
- Power Pro True connectors
| Light Source Type | LED |
|---|
| Light Source Quantity | 15 |
|---|
| Light Source Power | 10 W |
|---|
| LED Colour Type | RGBWAUV |
|---|
| Refresh Rate | 4200 Hz |
|---|
| Luminous Flux (Total) | 3600 lm |
|---|
| Beam Angle (Horizontal) | 33° |
|---|
| Beam Angle (Vertical) | 22° |
|---|
| Control Mode | Auto / DMX / Manual / Master Slave / Remote |
|---|
| DMX Channels | 6 / 8 / 11 / 90 / 95 |
|---|
| Protocols | DMX / RDM |
|---|
| Display | OLED |
|---|
| Dimmer | 0-100 % |
|---|
| Strobe | 0-18 Hz |
|---|
| Power Supply | 100-240 V AC 50/60 Hz |
|---|
| Power Consumption | 136 W |
|---|
| Power Connector In | Power Pro True |
|---|
| Power Connector Out | Power Pro True |
|---|
| DMX Connector | XLR 3P In/Out |
|---|
| DMX Connector In | XLR 3P |
|---|
| DMX Connector Out | XLR 3P |
|---|
| Length (mm) | 995 mm |
|---|
| Width (mm) | 80 mm |
|---|
| Height (mm) | 190 mm |
|---|
| Weight | 7.7 kg |
|---|
| IP Rating | IP65 |
|---|
| Housing | Aluminium die-cast |
|---|
| Colour | Black |
|---|
| Maximum Ambient Temperature | 40 °C |
|---|
| Minimum Operating Temperature | -5 °C |
|---|
| Cooling | Convection |
|---|
| Mounting Options | Bracket |
|---|
| Included Cables | Power Pro True Cable |
|---|
