DI box attivo ADI-101 - DAP D1946
DI box attivo ADI-101 - DAP D1946
DI box attivo ADI-101 - DAP D1946
DI box attivo ADI-101 - DAP D1946
DI box attivo ADI-101 - DAP D1946

DI box attivo ADI-101 - DAP D1946

DAP
74,13 €
Tasse incluse
Mono active DI box
Condividi

The DAP ADI-101 is made for professionals who do not want to troubleshoot signal interference. It protects your system against ground loops and possible hum and buzzing noises. Thanks to its metal housing and rubber feet, it is road-proof.

The ADI-101 can be powered by a 9 V battery or 18-48 V phantom power. In addition, it has a 0/20/40 dB attenuation switch.

  • Prevents ground loops, hum and buzz
  • Low distortion
  • Ground lift switch
  • 0, 20 and 40 dB attenuation switch
  • Works with 9 V battery or 18-48 V phantom power
  • Road proof housing with rubber feet
Mono Inputs1
Mono Input Connector3-pin XLR / TS unbalanced 6.3 mm
Mono Input Impedance250000 Ω
Main Outputs1
Main Output Connector3-pin XLR / TS unbalanced 6.3 mm
Main Output Impedance600 Ω
THD Level %< 0.005 %
Signal-to-noise Ratio> 105 dB
Frequency Response Minimum10 Hz
Frequency Response Maximum40000 Hz
Phantom Power18 V / 24 V / 48 V
Attenuation-20dB / -40dB
Battery Type9 V block PP3
Battery Voltage9 V
Height (mm)53 mm
Width (mm)158 mm
Length (mm)120 mm
HousingMetal
Weight0.8 kg
IP RatingIP20 (indoor use only)
ColourBlack
LED IndicatorsPower

  • Marca
  • Riferimento
    D1946
  • In magazzino
    10 Articoli
  • ean13
    8717748320476
