Dimmer LED 12 canali DMX 15A RGB/RGBW OLED - Artecta A9915045
Dimmer LED 12 canali DMX 15A RGB/RGBW OLED - Artecta A9915045

Dimmer LED 12 canali DMX 15A RGB/RGBW OLED - Artecta A9915045

ARTECTA
385,55 €
Tasse incluse
Constant Voltage - 12x 4-channel, Max 30A - PWM LED Dimmer
Condividi

The LED DIM-12 dimmer is a universal and versatile PWM dimmer which is suitable to use with constant voltage LED strips. It has 12 outputs which all can control 4-channel strips with a working voltage of 12 V to 24 V. Settings can be done easily by the OLED display. DMX connections can be done by RJ45 or 3-pin DMX plugs. The power supply as well the connections of the LEDs are user friendly by (easy removable) Phoenix terminal connections.

  • 12 outputs of RGB or RGBW
  • Clear OLED display for easy setup
  • Including Phoenix terminals
  • Control by DMX or stand alone
Control ModeDMX
DMX Channels48
ProtocolsDMX
BTNo
Power Supply12-24 V DC
Output voltage12-24 V DC
Maximum Output Current (A)15 A
Power Connector InTerminal
Power Connector OutTerminal
DMX Connector InRJ45 / XLR 3P
DMX Connector OutRJ45 / XLR 3P
Length (mm)286 mm
Height (mm)90 mm
Width (mm)62 mm
IP RatingIP20 (indoor use only)
HousingMetal
ColourBlack
Maximum Ambient Temperature40 °C
Minimum Ambient Temperature0 °C

  • Marca
  • Riferimento
    A9915045
  • In magazzino
    10 Articoli
  • ean13
    8717748466471
