The Showtec Performer Profile Zoom 150 Q6 is an indoor 150-watt RGBACL LED profile with a high CRI of 95 for situations that demand a high quality of light. It has a wide (manual) zoom range from 25 to 50 degrees. It is dimmable from 0 to 100% in 16-bit steps and its framing system, which is integrated in the optic system, lets you accurately determine the field of light. The Performer Profile Zoom 150 Q6 supports DMX and RDM. It has a strobe function that works from 0 to 25 Hz, and its forced convection cooling is silent enough to make it suitable for (TV) studios, theatres, and museums.
- 150 W RGBACL LED
- Manual zoom from 25° to 50°
- High CRI for accurate colour rendering
- Integrated framing shutter system
- DMX & RDM
- 16-bit dimming
| Light Source Type | LED |
|---|
| Light Source Quantity | 1 |
|---|
| Light Source Power | 150 W |
|---|
| LED Colour Type | R / G / B / A / C / L |
|---|
| Refresh Rate (Max.) | 25 kHz |
|---|
| Illuminance @ 2 m | 1588 lx |
|---|
| Illuminance @ 3 m | 706 lx |
|---|
| Illuminance @ 5 m | 254 lx |
|---|
| Luminous Flux (Total) | 2624 lm |
|---|
| CRI | 95 |
|---|
| Minimum CCT | 1800 K |
|---|
| Maximum CCT | 10000 K |
|---|
| Zoom Type | Manual |
|---|
| Zoom Ratio | 1:2 |
|---|
| Zoom Minimum | 25° |
|---|
| Zoom Maximum | 50° |
|---|
| Control Mode | DMX / Manual |
|---|
| DMX Channels | 3 / 7 / 8 / 10 / 13 / 20 |
|---|
| Protocols | DMX / RDM |
|---|
| Display | OLED |
|---|
| Display Size | 1.3" |
|---|
| Fan mode | Yes |
|---|
| Dimmer | 0-100 % |
|---|
| Strobe | 0-25 Hz |
|---|
| Power Supply | 100-240 V AC 50/60 Hz |
|---|
| Power Consumption | 170 W |
|---|
| Fuse | 3.15 A |
|---|
| Power Connector In | Power Pro True |
|---|
| DMX Connector | XLR 5P In/Out |
|---|
| DMX Connector In | XLR 5P |
|---|
| DMX Connector Out | XLR 5P |
|---|
| Length (mm) | 568 mm |
|---|
| Width (mm) | 224 mm |
|---|
| Height (mm) | 191 mm |
|---|
| Weight | 6.1 kg |
|---|
| IP Rating | IP20 (indoor use only) |
|---|
| Housing | ABS / Aluminium / Steel |
|---|
| Colour | Black |
|---|
| Cooling | Convection/Axial fan |
|---|
| Mounting Options | Bracket |
|---|
| Safety Attachment | Yes |
|---|
| Safety Eyes | 1 |
|---|
| Maximum Ambient Temperature | 45 °C |
|---|
| Minimum Operating Temperature | 0 °C |
|---|
| Included Cables | Power Pro True Cable |
|---|
