Connettore XLR 3P chassis maschio, contatti oro, nero, per foro D - Seetronic MJ3F2CBG

Connettore XLR 3P chassis maschio, contatti oro, nero, per foro D - Seetronic MJ3F2CBG

SEETRONIC
€2.59
Tax included
Gold contacts - black housing
Share

This 3-pin XLR chassis connector has a zinc diecast housing and fits D-size mounting holes. It can be installed from the front or the rear of a panel.

  • For D-size mounting holes
  • Gold-plated contacts
  • UL94-V0 flame retardant
Flashover Voltage1500 V
Rated Current (A)16 A
Pins3
PCB MountNo
Length (mm)31 mm
Height (mm)24 mm
Width (mm)26 mm
IP RatingIP40
HousingMetal
ColourBlack
Contact Resistance5 < mΩ
Pin ConnectionSolder
Locking DeviceLatch
Contact TypeGold plated
Maximum Ambient Temperature80 °C
Minimum Ambient Temperature-30 °C

  • Brand
  • Reference
    MJ3F2CBG
  • In stock
    10 Items
  • EAN13
    8717748549686
