Subwoofer da incasso a soffitto 8" 50W 70/100V - DAP D6588
The DAP CS-850S is an 8-inch recessed ceiling subwoofer for augmenting the low frequency range (28-200 Hz) of a 70 V or 100 V audio infrastructure. It has been tailored to produce only the low end of the frequency spectrum by using a passive lowpass filter. The volume can be adapted to match the volume of other components in the system using the multiple power taps on the transformer. The three quick-turn mounting screws allow for an easy and sturdy installation in a Ø 230 mm hole.
Tip: The housing is made from ABS and the colour is a neutral white. The frame and the grille can be painted to match your interior. Best practice is to paint both the frame and the grille before installing them.
- 50 W peak power - 70/100 V
- Five power taps (3, 5, 15, 30 and 50 W)
- IP20
- Robust ABS housing
| Peak Input Power | 50 W |
|---|---|
| Transformer | 70+100 V |
| Line Transformer Taps | 3 / 5 / 15 / 30 / 50 W |
| Passive Input Connection | Open End |
| Speaker System | Subwoofer |
| Speaker Sensitivity (1 W/1 m) | 90 dB |
| Frequency Response Minimum | 28 Hz |
| Frequency Response Maximum | 200 Hz |
| Woofer Diameter | 8" |
| Height (mm) | 165 mm |
| Width (mm) | 260 mm |
| Length (mm) | 260 mm |
| Weight | 3 kg |
| IP Rating | IP20 (indoor use only) |
| Mounting Size | Ø 230 mm |
