Connettore Power Pro cavo CA 20A/250V blu - Seetronic SAC3FCA

Name: Connettore Power Pro cavo CA 20A/250V blu - Seetronic SAC3FCA
Brand: SEETRONIC
SKU: SAC3FCA
Price: 6.28 EUR
Availability: InStock

SEETRONIC

6,28 €

Tasse incluse

Blue

The Power Pro Connector is a locking, AC cable connector with contacts for line, neutral, and pre-mating ground contact. It is used as an appliance coupler wherever a rugged solution in combination with a locking system is needed in order to guarantee a safe power connection. Two cable chucks are included for smaller and larger diameter cables.

Locking 20 A/250 V AC 3-way cable connector
Silver-plated contacts
UL94-V0 flame retardant

Rated Current (A)	20 A
Flashover Voltage	4000 V
Cable Entry	8-12 mm
Pins	3
Minimum Wire Size	0.75 mm²
Maximum Wire Size	2.5 mm²
Maximum Wire Size AWG	12 AWG
Length (mm)	76.5 mm
Height (mm)	26 mm
Width (mm)	26 mm
Weight	0.04 kg
IP Rating	IP20 (indoor use only)
Housing	Polyamide
Colour	Blue
Pin Connection	Screw Terminal
Locking Device	Latch
Contact Type	Silver plated
Maximum Ambient Temperature	80 °C
Minimum Ambient Temperature	-30 °C
