Connettore XLR 3P chassis maschio, contatti argento, nero, per foro D - Seetronic MJ3F2CB

Connettore XLR 3P chassis maschio, contatti argento, nero, per foro D - Seetronic MJ3F2CB

SEETRONIC
2,04 €
Tasse incluse
Silver contacts - black housing
Condividi

This 3-pin XLR chassis connector has a zinc diecast housing and fits D-size mounting holes. It can be installed from the front or the rear of a panel.

  • For D-size mounting holes
  • Silver-plated contacts
  • UL94-V0 flame retardant
Flashover Voltage1500 V
Rated Current (A)16 A
Pins3
PCB MountNo
Length (mm)25 mm
Height (mm)31 mm
Width (mm)26 mm
IP RatingIP40
HousingMetal
ColourBlack
Contact Resistance5 < mΩ
Pin ConnectionSolder
Locking DeviceLatch
Contact TypeSilver plated
Maximum Ambient Temperature80 °C
Minimum Ambient Temperature-30 °C

  • Marca
  • Riferimento
    MJ3F2CB
  • In magazzino
    10 Articoli
  • ean13
    8717748549679
