XLR 3P chassis femmina IP65 - Seetronic K3F2CWB

XLR 3P chassis femmina IP65 - Seetronic K3F2CWB

SEETRONIC
4,79 €
Tasse incluse
Gold contacts - black housing
Condividi

This 3-pin air-tight and waterproof XLR chassis connector has a zinc diecast front plate and polyamide housing, fitting D-size mounting holes. It has gold-plated contacts and comes with a protection cap and sealing gasket, making it IP65 rated and suitable for use in wet conditions. It must be installed from the front of the panel.

  • For D-size mounting holes
  • IP65 when using suitable IP65 counterpart (SCWM3B, not included)
  • Compatible with regular XLR 3-pin connectors
  • Gold-plated contacts
  • UL94-HB flame retardant
Flashover Voltage1500 V
Rated Current (A)16 A
Pins3
PCB MountNo
Length (mm)42.5 mm
Height (mm)33.1 mm
Width (mm)27.8 mm
IP RatingIP65 Front
HousingMetal
ColourBlack
Contact Resistance5 < mΩ
Pin ConnectionSolder
Locking DeviceLatch
Contact TypeGold plated
Maximum Ambient Temperature80 °C
Minimum Ambient Temperature-30 °C

  • Marca
  • Riferimento
    K3F2CWB
  • In magazzino
    10 Articoli
  • ean13
    8717748549792
