Cavo DMX/AES-EBU XLR 5P M/F 3m contatti argentati - DAP FLR083

Cavo DMX/AES-EBU XLR 5P M/F 3m contatti argentati - DAP FLR083

DAP
15,40 €
Tasse incluse
3 m - Silver plated
Condividi

The DAP FLR08 DMX/AES-EBU cable offers professional grade signal transmission, constructed with DAP DIG-110 digital cable and Rean RC5 connectors. The DIG-110 uses a braided shield for interference-free signal transmission. The RC5 connectors have silver-plated contacts to ensure low-impedance, high-quality connections for your signals. The sleek, black-plated zinc housing provides robust protection while maintaining a professional look. Each cable includes a transparent heat-shrink label sleeve for easy identification and a convenient hook-and-loop fastener to keep setups tidy.

  • 110-Ohm DMX cable
  • Silver-plated contacts
  • Black housing
  • Transparent heat-shrink label sleeve
  • Hook-and-loop fastener included
Connector 1XLR 5P Male
Connector 2XLR 5P Female
Brand Connector 1REAN
Impedance110 Ω
Cable Length3 m
Pins5
Conductor Resistance110 Ω/km
Conductor Capacitance35 pF/m
Capacity Inner Conduct. Shield/Inner Conduct.52 pF/m
Wire Connection3 mm²
Outer Cable Diameter7 mm
Outer Isolation TypePE
Weight0.2 kg
IP RatingIP20 (indoor use only)
MaterialCopper / PVC
ColourBlack
Contact TypeSilver plated
1st ShieldAluminium foil
2nd ShieldBraided Tinner Copper
Shield Resistance12.5 Ω/km
Filler MaterialPaper
Conductors2
Conductor ConstructionStranded Core
Maximum Ambient Temperature60 °C
Minimum Ambient Temperature-20 °C

  • Marca
  • Riferimento
    FLR083
  • In magazzino
    10 Articoli
  • ean13
    8717748584724
