Cavo digitale AES-EBU/DMX 110 Ohm 100 m su bobina Nero - DAP D9433B
Cavo digitale AES-EBU/DMX 110 Ohm 100 m su bobina Nero - DAP D9433B

Cavo digitale AES-EBU/DMX 110 Ohm 100 m su bobina Nero - DAP D9433B

DAP
106,23 €
Tasse incluse
110 Ohm Digital Cable - 100 m on spool - black
Condividi

110 Ohm Digital Cable, 100 m on spool.

Impedance110 Ω
On Spool or per metreOn Spool
Cable Length100 m
Conductor Resistance130 Ω/km
Conductor Capacitance20 pF/m
Capacity Inner Conduct. Shield/Inner Conduct.65 pF/m
Maximum Wire Size1.8 mm²
Outer Cable Diameter6 mm
Outer Isolation Diameter1.9 mm
Outer Isolation TypePE
MaterialPVC
ColourBlack
CPR Euroclass CableNo
1st ShieldBraided
2nd ShieldOxygen Free Copper
Shield Resistance12.5 Ω/km
Filler MaterialCotton / Paper
Conductors3
Maximum Ambient Temperature60 °C
Minimum Ambient Temperature-20 °C

  • Marca
  • Riferimento
    D9433B
  • In magazzino
    10 Articoli
  • ean13
    8717748042866
