CEE 32A/240V 3P Male Plug Black SHARK series - PCE 91317

CEE 32A/240V 3P Male Plug Black SHARK series - PCE 91317

PCE
25,86 €
Tasse incluse
Black - SHARK series
Condividi

The PCE CEE 32 A/240 V 3P Plug Male is a 240 volt connector for high currents (up to 32 A). It is made of PA6 and is IP44/IP54 rated. It has three poles (2P + PE) and brass terminals. Its clock position is 6h. Screw terminals are used for the wire connections.

Rated Current (A)32 A
Flashover Voltage240 V
Cable Entry11.5-20 mm
Pins3
Minimum Wire Size2.5 mm²
Maximum Wire Size6 mm²
Length (mm)150 mm
Height (mm)63 mm
Width (mm)63 mm
Weight0.178 kg
IP RatingIP44
MaterialPlastic
ColourBlack
Pin ConnectionScrew Terminal
Supplier Type Number023-6XV
Ground Lug Position6H
Contact TypeBrass
Maximum Ambient Temperature40 °C
Minimum Ambient Temperature-25 °C

  • Marca
  • Riferimento
    91317
  • In magazzino
    10 Articoli
  • ean13
    8717748594822
